Acoustic Signature MCX2Moving Coil Cartridge
- Free shipping on orders over € 100,- (NL)
- Returns possible within 14 days
- Pickup available (Vries, Drenthe)
Checkout our Sales and DiscountsThe Acoustic Signature MCX2 is a high-precision moving coil (MC) cartridge engineered for audiophiles who demand exceptional detail, clarity, and musicality from their vinyl playback. Featuring high-purity silver coils, a nude elliptical stylus, and a CNC-milled, resonance-optimized aluminum chassis, the MCX2 delivers a refined balance of warmth and transparency. Designed for medium to high mass tonearms, including Acoustic Signature’s NEO series, it ensures outstanding synergy with a wide range of turntables. With its finely tuned frequency response and spatial accuracy, the MCX2 provides an immersive and expressive listening experience, capturing every nuance of the music.
Key Features
- Nude Elliptical Stylus: Provides precise tracking and minimizes distortion.
- High-Purity Silver Coils: Ensures superior signal transfer and clarity.
- Resonance-Optimized Aluminum Chassis: Reduces unwanted vibrations for cleaner sound.
- Optimized Frequency Response: Slightly rolled-off highs create a smooth, natural timbre.
- Easy Mounting: Designed for effortless installation on medium to high mass tonearms.
Detailed Description
Nude Elliptical Stylus
The MCX2 features a nude elliptical stylus, which enables precise groove tracking and excellent retrieval of musical detail. This stylus shape reduces distortion and enhances transient response, ensuring a smooth and dynamic performance across all musical genres.
High-Purity Silver Coils
Unlike conventional MC cartridges, the MCX2 employs 4N silver coils, known for their excellent conductivity and ability to deliver a highly detailed sound signature. This design enhances signal integrity, allowing for an expressive and engaging audio presentation.
Resonance-Optimized Aluminum Chassis
The CNC-milled aluminum chassis is engineered using finite element design principles, which help minimize unwanted resonances. This ensures a purer sound output, allowing the music to shine without coloration or distortion.
Optimized Frequency Response
The MCX2’s slightly rolled-off high frequencies lend a velvety smooth timbre, preventing harshness while maintaining detail and transparency. This characteristic balances well with turntables that offer an energetic and dynamic playback, resulting in a rich and well-defined soundstage.
Easy Installation & Compatibility
Designed for medium to high mass tonearms, the MCX2 is easy to mount and configure. Its robust construction and precise tracking force range allow for flexible setup, ensuring optimal performance across various high-fidelity turntable systems.
Technical Specifications
| Cartridge Type | Moving Coil (MC) |
| Stylus Profile | Nude Elliptical |
| Coil Material | 4N Silver |
| Chassis Material | Resonance-Optimized Aluminum |
| Output Voltage | 0.55 mV (1 kHz, 5 cm/sec) |
| Channel Balance | < 1.5 dB @ 1 kHz |
| Channel Separation | > 21 dB @ 1 kHz |
| Dynamic Compliance | 15 m/mN |
| Tracking Force Range | 2.1 - 2.5 g |
| Recommended Tracking Force | 2.3 g (23 mN) |
| Frequency Response | 20 - 25,000 Hz (-3 dB) |
| Flat Response Range | ± 2.5 dB (20 - 20,000 Hz) |
| DC Resistance | 7 Ω |
| Recommended Load | 100 Ω |
| Cartridge Weight | 12.2 g |
User Manual
